Disc-O-Sem – Modular Seeding System
Main Series and Their Advantages
- Transform Your Equipment – Disc-O-Sem transforms a standard disc harrow into a multifunctional implement. This eliminates the need for a separate seeder and reduces the number of passes across the field, preserving soil moisture.
- Precise Dosing and Distribution – The system is equipped with an electric stainless steel metering unit that ensures precise seed distribution (from fine seeds to legumes). Pneumatic delivery guarantees uniformity across the entire working width.
- Perfect Synchronization with Discs – Seeds are placed immediately after the disc section and just before the press roller. This ensures that each seed lands in cultivated soil and is immediately pressed for optimal contact and rapid germination.
- Smart Control – The Disc-O-Sem system is fully compatible with ISOBUS standards. It allows for easy in-cab control, section control, and operation with variable rate seeding maps.
Technical Specifications
- Hopper Capacity: Available in various volumes (up to 1100 liters for mounted and more for trailed models).
- Compatibility: Specifically designed for the Disc-O-Mulch R and Gold series.
- Metering Unit: Stainless steel, electric motor-driven
Technical Specifications
Parameter
DS 200 Electric
DS 500 Hydraulic
Drive
Electric
Hydraulic
Hopper capacity (L)
200
500
Number of outlets
8
8
Weight (kg)
32
44 - 62
*Max. flow rate (Wheat) ** Flow rate data calculated at a working width of 6 m and a speed of 15 km/h.
25 kg/Ha
100 kg/Ha
